VariMax-motor50 NG
Article no: F22050401
- Adapted for variable speed control
- Compact built-in dimensions
- CE-approved
- Five-year product warranty
| Max torque | 4 Nm |
|---|---|
| Min. rotation speed | 1 rpm |
| Max. rotation speed | 375 rpm |
| Motor temperature mantle max | 110°C |
| Ambient temperature | -30 – +45 °C -40 – +45 °C (Note, at -40 °C, the control unit must be connected to power all the time) |
| Protection form | IP54 |
| Weight incl. motor bracket | 4 kg |
| Max rotor diameter, 12 RPM | 2500 mm |
